Multi-recognition Modes Facial Access Control Device HF FR701 FR701 manufacturer from China Chongqing Hui Fan Tech.Co.Ltd

Product Detail

Model No.: FR701

Production Capacity: 50000pcs/m

Delivery Date: 5-10 business days

Face capacity: 400

Communication: TCP/IP, RS232/485, USB Host

Wiegand signal: Wiegand in and out

Means of Transport: Ocean,Land,Air

Packing: carton box

Brand Name: HF security

Camera: High Resolution Infrared Ca...

Display: 3 inch touch screen

- Elegant ergonomic design
- 3.0 inch TFT touch screen
- 2 user-defined function keys
- Infra-red optical system
-- 50 time zones, 99 groups

Memory	256M Flash, 64M SDRAM
Hardware	Platform: ZEM600
Camera	High Resolution Infrared Camera
Display	3 Inch Touch Screen
Face Capacity	400
Fingerprint Capacity	2000
ID Card Capacity	10,000(optional function) I
Logs Capacity	100,000
2000mAh Backup Battery	N/A
Communication	TCP/IP, RS232/485, USB Host
Access Control Interfaces for	3rd party electric lock, door sensor, alarm, wired bell and exit button
Wiegand Signal	Wiegand in and out
Optional Functions	ID Card, Mifare card.
Power Supply	12V/3A
Verification Speed	≤2S
Operating temperature	0℃-45℃
Operating Humidity	20%-80%
